Pipe fitting elbow is a kind of pipe fittings commonly used in pipeline installation to provide flexibility to change the pipe direetion.
Pipe fitting elbow connects two pipes of the same nominal diameter or different diameter, so that the pipe bends at a certain angle,usually a 90 or 45 degrees.The ends may be machined for butt welding threaded or socketed. When the ends differ in size,it is known as a reducer pipe fitting elbow.
According to bend degree, there are 90 degree pipe fitting elbow and 45 degree pipe fitting elbow; according to length, there are long radius pipe fitting elbow and short radius pipe fitting elbow.
Product Description
| Standards | ASME/ANSI B16.9, ASME/ANSI B16.11, ASME/ANSI B16.28,JIS B2311, JIS B2312, DIN 2605, DIN 2615, DIN 2616, DIN 2617, BS 4504, GOST 17375, GOST 30753, GOST 17378 |
| Bending radius | Short Radius(SR), Long Radius(LR), 2D, 3D, 5D, multiple |
| Degree | 45 / 90 / 180, or customized degree |
| Size Range | Seamless type: ½" up to 28" |
| Welded type: 28"-to 72" | |
| WT Schedule | SCH STD,SCH10 to SCH160, XS, XXS, |
| Carbon Steel | A234 WPB, WPC; A106B, ASTM A420 WPL9, WPL3, WPL6, WPHY-42WPHY-46, WPHY-52, WPHY-60, WPHY-65, WPHY-70, |
| Alloy Steel | A234 WP1, WP11, WP12, WP22, WP5, WP9, WP91 |
| Special Alloy Steel | Inconel 600, Inconel 625, Inconel 718, Inconel X750, Incoloy 800, |
| Incoloy 800H, Incoloy 825, Hastelloy C276, Monel 400, Monel K500 | |
| WPS 31254 S32750, UNS S32760 | |
| Stainless Steel | ASTM A403 WP304/304L, WP316/316L, WP321, WP347, WPS 31254 |
| Duplex stainless steel | ASTM A 815 UNS S31803, UNS S32750, UNS S32760 |
| Applications | Petroleum industry, chemical, power plant, gas piping, shipbuilding. construction, sewage disposal,and nuclear power etc. |
| Packaging material | plywood cases or pallets, or as per customer's requirements |
pecification of 5D pipe Elbow
| Specifications | ASME B16.9 5d Elbow |
|---|---|
| 5d pipe elbow Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| 5d 45 degree elbow Pipe Fittings size | Seamless Butt Weld Fittings: 1/2" - 10" Welded Butt Weld Fittings: 1/2" - 48" |
| 5d bend Type | DN15-DN1200 |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom Pipe Fittings |
| 5d 90 degree elbow Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 5d long radius elbow Types | Seamless / ERW / Welded / Fabricated Pipe Fittings |
| Stainless Steel 5D Elbow Size Range | ½" NB to 24" NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) |
| 5d pipe elbow Fittings | Angle : 22.5 deg, 30deg, 45 deg, 90 deg, 180 deg, 1.0D, 1.5D, 2.0D, 2.5D, 3D, 4D, 5D, 6D, 7D-40D. Standard: ASME B16.9, ASME B16.28, ASME B16.25, MSS SP-75 DIN2605 JISB2311 JISB2312 JISB2313, BS, GB, ISO |
| Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Key markets and industries for 5d Elbow |
|
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| 5d long radius elbow Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Application |
|
Welcome to Shengtian
Hebei Shengtian Pipefitting Group Co.,Ltd is specialized in producing stainless steel pipe，stainless steel pipe fittings,stainless steel flanges,stainless steel elbows,stainless steel tees,cross, reducer (concentric and eccentric reducers),stub ends and caps. Products variety,sizes diverse,beautiful appearance,stable performance,not only have variety materials (201,301,304,304L,316,316L,321,310S）welding and seamless elbows,also can produce according to the standard of GB12459,ASTM 403,DIN 2605(elbow),DIN 2609(Stub End),DIN 2615 (TEE),DIN2616 (Reducers) standard pipe fittings,stainless steel pipe fittings include A & B series,long radius and short radius,and we can produce the special products according to clients request.
Our company produced stainless pipe fittings,stainless steel flanges etc products is wildly applied in chemical, petroleum, electric power,paper making,food,pharmaceutical,construction and other industries.Expand the market,establish a wide range of sales network,we sincerely welcome new and old customers to visit the factory,send the letter to negotiate business.
Due to the GOST A403 WP 316L SCH 10 Pipe 24" 5D Stainless Steel 180 Degree Elbows with good comprehensive performance, so it is widely used in chemical industry, building, water supply, water drainage, oil, light and heavy industry, freezing, sanitary, plumbing, fire protection, electric power, aerospace, shipbuilding and other infrastructure projects.
