Schedule 40 Ecc Reducer and Butt Weld Pipe Fittings are available in ASTM B16.9 304/304L or 316/316L Stainless Steel with a mill finished inner and outer diameter (ID/OD). These stainless weld fittings conform to ASTM A403, ASTM A960, MSS SP-4, ASTM B16.9 (except wall), and MSS SP-43. Schedule 40 fittings are Nominal Pipe Size (NPS), not Tube Outside Diameter (OD).
ASTM B16.9 Eccentric Reducer, ASME B16.9 Eccentric Reducer is usually installed on the centrifugal process suction pump nozzle in order to make easy and proper transition from the larger diameter suction piping to the pump suction nozzle. We are a highly experienced company in ASTM B16.9 Butt Weld Schedule 40 316L Stainless Steel Eccentric Reducer, ASTM B16.9 stainless steel reducer & other stainless steel pipe fittings.
Product Description
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Sizes | 1/2″NB TO 36 "NB IN |
| Types | Concentric Reducers, Eccentric Reducers |
| Wall Thickness | Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc. |
| Value Added Services | Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering |
| Production Grades | Stainless Steel |
| ASME: | ANSI B16.9, ANSI B16.28, MSS-SP-43 |
| DIN: | DIN2605, DIN2615, DIN2616, DIN2617, DIN28011 |
| EN: | EN10253-1, EN10253-2 |
| ASTM A403 - ASME SA403 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Fittings Buttwelding |
| ASME B16.25 | Buttwelding Ends |
| ASME B16.28 | Wrought Steel Short Radius Elbows and Buttwelding Returns |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| Stainless Steel Reducer | ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L |
| Carbon Steel Reducer | ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70. |
| Low Temperature Carbon Steel Reducer | ASTM A420 WPL3, A420 WPL6 |
| Alloy Steel Reducer | ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91 |
| Duplex Reducer | ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462 |
| Nickel Alloy Reducer | ASTM / ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL 400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL 600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOY C 276 ) |
We are Manufacturers, Supplier and Exporters of ASTM B16.9 Butt Weld Schedule 40 Stainless Steel Ecc Reducer. These reducers are ideal for critical applications that involve high pressure, impulse, vibration and temperature. ASTM B16.9 Butt Weld Schedule 40 Stainless Steel Ecc Reducers are tested and verified for durability, accuracy and precision.
ASME B 16.9 grade Stainless Steel Ecc reducers from Shengtian Group are used to properly reduce into and out of circulating pumps.
